INA ZKLFA1563-2Z
Price: 491.23 $
Specifications
| Brand | INA |
| Item Number | ZKLFA1563-2Z INA |
| Manufacturer Part Number | 0001307530000 |
| EAN | 4012802424744 |
| Category | Angular Contact Ball Bearing Double Row |
| Inner (d) MM | 15 |
| Outer (D) MM | 42 |
| Width (B) MM | 25 |
| Inner (d) Inch | 0.5906 |
| Outer (D) Inch | 1.6535 |
| Width (B) Inch | 0.9843 |
| Weight (kg) | 0.31 kg |
| Bore | C - Cylindrical Bore |
| Seal | ZZ/2Z - Steel Seal on Two Sides |
| Cage Type | S - Steel or Standard Cage |
| External Modification | No External Modification |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring | Split inner ring |
| Width (b) mm | 25 |
| Axial Static Load Rating C0a (N) | 28000 |
| Axial Dynamic Load Rating Ca (N) | 17900 |
| Limiting speed for grease lubrication (n G Grease) | 10800 |
| Thermally permissible speed (n u03d1) | 7000 |
| ECLASS number | 23-05-10-02 |
| ECLASS2 number | 23-05-10-02 |
| Medias description | Angular contact ball bearing units ZKLFA..-2Z, double direction, for screw mounting, gap seals on both sides |
| 2Z | Gap Seals At Both Sides Of The Bearing |
