INA ZKLFA1050-2RS

Specifications

Brand	INA
Item Number	ZKLFA1050-2RS INA
Manufacturer Part Number	0001309660000
EAN	4012802178166
Category	Angular Contact Ball Bearing Double Row

Weight and Dimensions

Inner (d) MM	10
Outer (D) MM	32
Width (B) MM	20
Inner (d) Inch	0.3937
Outer (D) Inch	1.2598
Width (B) Inch	0.7874
Weight (kg)	0.18 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	2RS - Rubber Seal on Two Sides
Cage Type	S - Steel or Standard Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Lubrication	Standard Lubrication
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring	Split inner ring

Data from Schaeffler (medias)

Width (b) mm	20
Axial Static Load Rating C0a (N)	18800
Axial Dynamic Load Rating Ca (N)	13400
Limiting speed for grease lubrication (n G Grease)	10900
Thermally permissible speed (n u03d1)	4600
ECLASS number	23-05-10-02
ECLASS2 number	23-05-10-02
Medias description	Angular contact ball bearing units ZKLFA..-2RS, double direction, for screw mounting, lip seals on both sides, with flattened flange

Suffix description

2RS	Lip Seal At Both Sides Of The Bearing, Axial Fitting
