INA ZKLF70155-2Z-XL

Specifications

Brand	INA
Item Number	ZKLF70155-2Z-XL INA
Manufacturer Part Number	0010068000000
Also known as	ZKLF70155-2Z
EAN	4012802078879
Category	Angular Contact Thrust Ball Bearings, Double Direction

Weight and Dimensions

Inner (d) MM	70
Outer (D) MM	155
Width (B) MM	45
Weight (kg)	4.9 kg

Product Properties

Cage Type	P - Plastic Molded Cage
Precision	P4 Precision (Higher than P5)

Data from Schaeffler (medias)

Width (b) mm	45
Axial Static Load Rating C0a (N)	241000
Axial Dynamic Load Rating Ca (N)	97000
Limiting speed for grease lubrication (n G Grease)	3800
Thermally safe operating speed (n u03d1)	2800
ECLASS number	23-05-10-02
ECLASS2 number	23-05-10-02
Medias description	Axial angular contact ball bearings ZKLF..-2Z, double direction, for screw mounting, gap seals on both sides

Suffix description

2Z	Gap Seals At Both Sides Of The Bearing
XL	X-Life
