INA ZKLF40100-2RS-2AP-XL

Specifications

Brand	INA
Item Number	ZKLF40100-2RS-2AP-XL INA
Manufacturer Part Number	0000741790000
Also known as	ZKLF40100-2RS-2AP
EAN	4012802078800
Category	Angular Contact Thrust Ball Bearings, Double Direction

Weight and Dimensions

Inner (d) MM	40
Outer (D) MM	100
Width (B) MM	68
Weight (kg)	2.9 kg

Product Properties

Cage Type	P - Plastic Molded Cage
Precision	Matched Pair

Data from Schaeffler (medias)

Width (b) mm	68
Axial Static Load Rating C0a (N)	202000
Axial Dynamic Load Rating Ca (N)	77000
Limiting speed for grease lubrication (n G Grease)	4000
Thermally safe operating speed (n u03d1)	1800
ECLASS number	23-05-10-02
ECLASS2 number	23-05-10-02
Medias description	Axial angular contact ball bearing ZKLF..-2RS-2AP-XL, double direction, screw mounting

Suffix description

2RS	Rubber Seals At Each Side Of The Bearing
2AP	Matched Pair (Twice The Number Of Bearings, Than Without 2AP)
XL	X-Life
