INA ZKLF3590-2RS-2AP-XL

Specifications

Brand	INA
Item Number	ZKLF3590-2RS-2AP-XL INA
Manufacturer Part Number	0002002470000
Also known as	ZKLF3590-2RS-2AP
EAN	4012802283945
Category	Angular Contact Thrust Ball Bearings, Double Direction

Weight and Dimensions

Inner (d) MM	35
Outer (D) MM	90
Width (B) MM	68
Weight (kg)	2.3 kg

Product Properties

Cage Type	P - Plastic Molded Cage
Precision	Matched Pair

Data from Schaeffler (medias)

Width (b) mm	68
Axial Static Load Rating C0a (N)	177000
Axial Dynamic Load Rating Ca (N)	73000
Limiting speed for grease lubrication (n G Grease)	4400
Thermally safe operating speed (n u03d1)	2000
ECLASS number	23-05-10-02
ECLASS2 number	23-05-10-02
Medias description	Axial angular contact ball bearing ZKLF..-2RS-2AP-XL, double direction, screw mounting

Suffix description

2RS	Rubber Seals At Each Side Of The Bearing
2AP	Matched Pair (Twice The Number Of Bearings, Than Without 2AP)
XL	X-Life
