INA ZARN5090-TV-A

Price: 939.44 $

Specifications

Brand	INA
Item Number	ZARN5090-TV-A INA
Manufacturer Part Number	0016825550000
EAN	4012802421255
Category	Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM	50
Outer (D) MM	90
Width (B) MM	60
Inner (d) Inch	1.9685
Outer (D) Inch	3.5433
Width (B) Inch	2.3622
Weight (kg)	1.43 kg

Product Properties

Seal

No Seal

Data from Schaeffler (medias)

Height (H) mm	60
Radial Static Load Rating C0r (N)	82000
Radial Dynamic Load Rating Cr (N)	40000
Axial Static Load Rating C0a (N)	300000
Axial Dynamic Load Rating Ca (N)	90000
Limiting speed for grease lubrication (n G Grease)	1200
Limiting speed for oil lubrication (n G Oil)	3600
ECLASS number	23-05-12-90
ECLASS2 number	23-05-12-90
Medias description	Needle roller/axial cylindrical roller bearings ZARN, double direction

Suffix description

Polyamide Cage

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
