INA ZARN3585-TV-A

Specifications

Brand	INA
Item Number	ZARN3585-TV-A INA
Manufacturer Part Number	0016828140000
EAN	4012802439984
Category	Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM	35
Outer (D) MM	85
Width (B) MM	66
Inner (d) Inch	1.378
Outer (D) Inch	3.3465
Width (B) Inch	2.5984
Weight (kg)	1.65 kg

Product Properties

Seal

No Seal

Data from Schaeffler (medias)

Height (H) mm	66
Radial Static Load Rating C0r (N)	53000
Radial Dynamic Load Rating Cr (N)	27500
Axial Static Load Rating C0a (N)	265000
Axial Dynamic Load Rating Ca (N)	105000
Limiting speed for grease lubrication (n G Grease)	1250
Limiting speed for oil lubrication (n G Oil)	4000
ECLASS number	23-05-12-90
ECLASS2 number	23-05-12-90
Medias description	Needle roller/axial cylindrical roller bearings ZARN, double direction

Suffix description

TV

Polyamide Cage

A

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
