INA ZARN3080-L-TV-A

Specifications

Brand	INA
Item Number	ZARN3080-L-TV-A INA
Manufacturer Part Number	0016827840000
EAN	4012802439960
Category	Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM	30
Outer (D) MM	80
Width (B) MM	66
Inner (d) Inch	1.1811
Outer (D) Inch	3.1496
Width (B) Inch	2.5984
Weight (kg)	1.5 kg

Product Properties

Seal

No Seal

Data from Schaeffler (medias)

Height (H) mm	82
Radial Static Load Rating C0r (N)	47000
Radial Dynamic Load Rating Cr (N)	26000
Axial Static Load Rating C0a (N)	265000
Axial Dynamic Load Rating Ca (N)	107000
Limiting speed for grease lubrication (n G Grease)	1300
Limiting speed for oil lubrication (n G Oil)	4400
ECLASS number	23-05-12-90
ECLASS2 number	23-05-12-90
Medias description	Needle roller/axial cylindrical roller bearings ZARN..-L, double direction, long shaft locating washer

Suffix description

L	Long Locating Washers
TV	Polyamide Cage
A	The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
