INA ZARF40100-L-TV-A

Specifications

Brand	INA
Item Number	ZARF40100-L-TV-A INA
Manufacturer Part Number	0016824660000
EAN	4012802078206
Category	Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM	40
Outer (D) MM	100
Width (B) MM	70
Inner (d) Inch	1.5748
Outer (D) Inch	3.937
Width (B) Inch	2.7559
Weight (kg)	1.45 kg

Product Properties

Seal

No Seal

Data from Schaeffler (medias)

Height (H) mm	70
Radial Static Load Rating C0r (N)	53000
Radial Dynamic Load Rating Cr (N)	27500
Axial Static Load Rating C0a (N)	163000
Axial Dynamic Load Rating Ca (N)	59000
Limiting speed for grease lubrication (n G Grease)	1600
Limiting speed for oil lubrication (n G Oil)	4400
ECLASS number	23-05-12-03
ECLASS2 number	23-05-12-03
Medias description	Needle roller/axial cylindrical roller bearings ZARF..-L, double direction, for screw mounting, long shaft locating washer

Suffix description

L	Long Locating Washers
TV	Polyamide Cage
A	The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
