INA ZARF30105-TV-A

Specifications

Brand	INA
Item Number	ZARF30105-TV-A INA
Manufacturer Part Number	0016827920000
EAN	4012802422573
Category	Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM	30
Outer (D) MM	105
Width (B) MM	66
Inner (d) Inch	1.1811
Outer (D) Inch	4.1339
Width (B) Inch	2.5984
Weight (kg)	1.95 kg

Product Properties

Seal

No Seal

Data from Schaeffler (medias)

Height (H) mm	66
Radial Static Load Rating C0r (N)	47000
Radial Dynamic Load Rating Cr (N)	26000
Axial Static Load Rating C0a (N)	265000
Axial Dynamic Load Rating Ca (N)	107000
Fatigue load limit, radial (C ur)	6800
Fatigue load limit, axial (C ua)	22900
ECLASS number	23-05-12-03
ECLASS2 number	23-05-12-03
Medias description	Needle roller/axial cylindrical roller bearings ZARF, double direction, for screw mounting

Suffix description

TV

Polyamide Cage

A

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
