INA ZARF2590-TV-A

Specifications

Brand	INA
Item Number	ZARF2590-TV-A INA
Manufacturer Part Number	0016827330000
EAN	4012802443219
Category	Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM	25
Outer (D) MM	90
Width (B) MM	60
Inner (d) Inch	0.9843
Outer (D) Inch	3.5433
Width (B) Inch	2.3622
Weight (kg)	0.435 kg

Product Properties

Seal

No Seal

Data from Schaeffler (medias)

Height (H) mm	60
Radial Static Load Rating C0r (N)	41500
Radial Dynamic Load Rating Cr (N)	24300
Axial Static Load Rating C0a (N)	199000
Axial Dynamic Load Rating Ca (N)	80000
Fatigue load limit, radial (C ur)	6000
Fatigue load limit, axial (C ua)	18600
ECLASS number	23-05-12-03
ECLASS2 number	23-05-12-03
Medias description	Needle roller/axial cylindrical roller bearings ZARF, double direction, for screw mounting

Suffix description

TV

Polyamide Cage

A

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
