INA ZARF1560-TV-A

Specifications

Brand	INA
Item Number	ZARF1560-TV-A INA
Manufacturer Part Number	0016819070000
EAN	4012802469967
Category	Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM	15
Outer (D) MM	60
Width (B) MM	40
Inner (d) Inch	0.5906
Outer (D) Inch	2.3622
Width (B) Inch	1.5748
Weight (kg)	0.42 kg

Product Properties

Seal

No Seal

Data from Schaeffler (medias)

Height (H) mm	40
Radial Static Load Rating C0r (N)	17500
Radial Dynamic Load Rating Cr (N)	13000
Axial Static Load Rating C0a (N)	53000
Axial Dynamic Load Rating Ca (N)	24900
Fatigue load limit, radial (C ur)	2650
Fatigue load limit, axial (C ua)	7500
ECLASS number	23-05-12-03
ECLASS2 number	23-05-12-03
Medias description	Needle roller/axial cylindrical roller bearings ZARF, double direction, for screw mounting

Suffix description

TV

Polyamide Cage

A

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
