INA VU200260

Specifications

Brand	INA
Item Number	VU200260 INA
Manufacturer Part Number	0013268050000
EAN	4012802137316
Category	Four Point Contact Ball Bearing

Weight and Dimensions

Inner (d) MM	191
Outer (D) MM	329
Width (B) MM	46
Inner (d) Inch	7.5197
Outer (D) Inch	12.9528
Width (B) Inch	1.811
Weight (kg)	15 kg

Product Properties

Seal	2RS - Rubber Seal on Two Sides
Cage Type	S - Steel or Standard Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring	Standard

Data from Schaeffler (medias)

Outside Diameter (D a) mm	329
Radial Static Load Rating C0r (N)	295000
Radial Dynamic Load Rating Cr (N)	165000
Axial Static Load Rating C0a (N)	650000
Axial Dynamic Load Rating Ca (N)	181000
Width inner ring (h i) mm	41
Width outer ring (h a) mm	41
ECLASS number	23-05-14-90
ECLASS2 number	23-05-14-90
Medias description	Four point contact bearings without gear teeth, sealed on both sides
