INA VU130225
Price: 1,523.54 $
Specifications
| Brand | INA |
| Item Number | VU130225 INA |
| Manufacturer Part Number | 0017338770000 |
| EAN | 4012802137293 |
| Category | Four Point Contact Ball Bearing |
| Inner (d) MM | 200 |
| Outer (D) MM | 290 |
| Width (B) MM | 24 |
| Inner (d) Inch | 7.874 |
| Outer (D) Inch | 11.4173 |
| Width (B) Inch | 0.9449 |
| Weight (kg) | 5.4 kg |
| Seal | 2RS - Rubber Seal on Two Sides |
| Cage Type | S - Steel or Standard Cage |
| External Modification | No External Modification |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring | Standard |
| Outside Diameter (D a) mm | 290 |
| Radial Static Load Rating C0r (N) | 93000 |
| Radial Dynamic Load Rating Cr (N) | 43500 |
| Axial Static Load Rating C0a (N) | 203000 |
| Axial Dynamic Load Rating Ca (N) | 48000 |
| Width inner ring (h i) mm | 24 |
| Width outer ring (h a) mm | 24 |
| ECLASS number | 23-05-14-90 |
| ECLASS2 number | 23-05-14-90 |
| Medias description | Four point contact bearings without gear teeth, sealed on both sides |
