INA VSU200544-VSP-ZT

Specifications

Brand	INA
Item Number	VSU200544-VSP-ZT INA
Manufacturer Part Number	0035581500000
EAN	4054366143938
Category	Slewing

Weight and Dimensions

Inner (d) MM	472
Outer (D) MM	616
Width (B) MM	56
Inner (d) Inch	18.5827
Outer (D) Inch	24.252
Width (B) Inch	2.2047
Weight (kg)	37 kg

Product Properties

Seal	2L - LS-seal at Both Sides
Cage Type	S - Steel or Standard Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring	Standard

Data from Schaeffler (medias)

Outside Diameter (D a) mm	616
Width inner ring (h i) mm	44,5
Width outer ring (h a) mm	44,5
ECLASS number	23-05-14-90
ECLASS2 number	23-05-14-90

Suffix description

VSP	For Mounting With An Axially Supported L-Section Ring In Series YRT. In Fitting Of The Series YRT With An L-Section Ring Supported Axially Over Its Whole Surface, There Is An Increase In The Axial Rigidity In The Direction Of The Support Ring As A Function Of The Support Ring Rigidity And In The Tilting Rigidity Of Up To 20%. In This Case, Delivery With A Different Preload Match Is Necessary
ZT	Centring On Inner And Outer Rings
