INA VSU200414-VSP-ZT
Price: 3,515.01 $
Specifications
| Brand | INA |
| Item Number | VSU200414-VSP-ZT INA |
| Manufacturer Part Number | 0003518220000 |
| EAN | 4054365629037 |
| Category | Slewing |
| Inner (d) MM | 342 |
| Outer (D) MM | 486 |
| Width (B) MM | 56 |
| Weight (kg) | 29 kg |
| Outside Diameter (D a) mm | 486 |
| Width inner ring (h i) mm | 44,5 |
| Width outer ring (h a) mm | 44,5 |
| ECLASS number | 23-05-14-90 |
| ECLASS2 number | 23-05-14-90 |
| VSP | For Mounting With An Axially Supported L-Section Ring In Series YRT. In Fitting Of The Series YRT With An L-Section Ring Supported Axially Over Its Whole Surface, There Is An Increase In The Axial Rigidity In The Direction Of The Support Ring As A Function Of The Support Ring Rigidity And In The Tilting Rigidity Of Up To 20%. In This Case, Delivery With A Different Preload Match Is Necessary |
| ZT | Centring On Inner And Outer Rings |
INA VSU200414
29 kg
342x486x56 mm
SKF RKS-060-20-0414
29 kg
342x486x56 mm
Torriani Gianni S.n.c. VSU200414 Torriani Gianni S-n-c-
29 kg
342x486x56 mm
INA VSU200414-RR
29 kg
342x486x56 mm
INA VSU200414-VSP
29 kg
342x486x56 mm
QCB VSU200414
29 kg
342x486x56 mm
Neutral SD486-20-00RCSP
29 kg
342x486x56 mm
Torriani Gianni S.n.c. SD-486-20-00-B Torriani Gianni S-n-c-
29 kg
342x486x56 mm
Neutral SD-486-20-00-B
29 kg
342x486x56 mm
INA VLU201094-ZT
62.5 kg
342x486x56 mm
INA VSU200414-ZT
29 kg
342x486x56 mm
