INA VLI200414-N-VSP

Specifications

Brand	INA
Item Number	VLI200414-N-VSP INA
Manufacturer Part Number	0010306800000
EAN	4047643185431
Category	Four Point Contact Ball Bearing

Weight and Dimensions

Inner (d) MM	325
Outer (D) MM	518
Width (B) MM	56
Weight (kg)	27.5 kg

Product Properties

Seal	2L - LS-seal at Both Sides
Cage Type	S - Steel or Standard Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring	Standard

Data from Schaeffler (medias)

Height (H) mm	56
Outside Diameter (D a) mm	518
Width inner ring (h i) mm	44,5
ECLASS number	23-05-14-90
ECLASS2 number	23-05-14-90

Suffix description

N	Normalized Gear Teeth On Bearing Ring
VSP	For Mounting With An Axially Supported L-Section Ring In Series YRT. In Fitting Of The Series Yrt With An L-Section Ring Supported Axially Over Its Whole Surface, There Is An Increase In The Axial Rigidity In The Direction Of The Support Ring As A Function Of The Support Ring Rigidity And In The Tilting Rigidity Of Up To 20%. In This Case, Delivery With A Different Preload Match Is Necessary
