INA TCJT35-XL-N

Specifications

Brand	INA
Item Number	TCJT35-XL-N INA
Manufacturer Part Number	0008569320000
Also known as	TCJT35-N
EAN	4012802799033
Category	Housing and Bearing (assembly)

Weight and Dimensions

Inner (d) MM	35
Outer (D) MM	155
Width (B) MM	53,5
Inner (d) Inch	1.378
Outer (D) Inch	6.1024
Width (B) Inch	2.1063
Weight (kg)	1.2 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Flange width (L) mm	92
Height flange (H) mm	155
Total height unit (U) mm	53,5
Radial Static Load Rating C0r (N)	15300
Radial Dynamic Load Rating Cr (N)	27500
Basic static load rating, radial (C 0r)	"15300.0000"
ECLASS number	23-05-16-02
ECLASS2 number	23-05-16-02
Medias description	Housing units TCJT, two-bolt flanged housing units, cast iron, eccentric locking collar, T seals

Suffix description

XL	X-Life
N	Cast Iron Housing With Undercut Slot For End Caps
