INA SL192319-TB-XL

Price: 868.87 $

Specifications

Brand	INA
Item Number	SL192319-TB-XL INA
Manufacturer Part Number	0572429410000
Also known as	SL192319-TB
EAN	4054366757586
Category	Cylindrical Roller Bearing Single Row

Weight and Dimensions

Inner (d) MM	95
Outer (D) MM	200
Width (B) MM	67
Inner (d) Inch	3.7402
Outer (D) Inch	7.874
Width (B) Inch	2.6378
Weight (kg)	10.27 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	FC - Full Complement, No Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

Width (b) mm	67
Radial Static Load Rating C0r (N)	710000
Radial Dynamic Load Rating Cr (N)	650000
Basic static load rating, radial (C 0r)	"710000.0000"
Limiting speed (n G)	2600
Reference speed (n u03d1r)	1620
ECLASS number	23-05-09-01
ECLASS2 number	23-05-09-01
Medias description	Cylindrical roller bearing SL1923, full compl, roller set self-retaining, single row, semi-locating bearing, 2 ribs on outer ring, 1 rib on inner ring, type SL19

Suffix description

In The Case Of Bearings Of TB Design, The Axial Load Carrying Capacity Of Cylindrical Roller Bearings Was Significantly Improved With The Aid Of New Calculation And Manufacturing Methods. Optimum Contact Conditions Between The Roller And Rib Are Ensured By Means Of A Special Curvature Of The Roller End Faces. As A Result, The Axial Contact Pressures On The Rib Are Significantly Minimised And A Lubricant Film Capable Of Supporting Higher Loads Is Formed. Under Normal Operating Conditions, Wear And Fatigue At The Rib Contact Running And Roller End Faces Is Completely Eliminated. In Addition, Axial Frictional Torque Is Reduced By Up To 50%. The Bearing Temperature During Operation Is Therefore Significantly Lower

X-Life
