INA SL185040-TB-C3

Price: 3,506.62 $

Specifications

Brand	INA
Item Number	SL185040-TB-C3 INA
Manufacturer Part Number	0535278100030
EAN	4012802395099
Category	Cylindrical Roller Bearing Double Row

Weight and Dimensions

Inner (d) MM	200
Outer (D) MM	310
Width (B) MM	150
Inner (d) Inch	7.874
Outer (D) Inch	12.2047
Width (B) Inch	5.9055
Weight (kg)	41 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	FC - Full Complement, No Cage
External Modification	No External Modification
Radial Internal Play	C3 Internal Play (Higher than Cn)
Precision	Standard Precision
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

Width (b) mm	150
Basic static load rating, radial (C 0r)	3000000
Limiting speed (n G)	1230
Reference speed (n u03d1r)	710
ECLASS number	23-05-09-01
ECLASS2 number	23-05-09-01

Suffix description

In The Case Of Bearings Of TB Design, The Axial Load Carrying Capacity Of Cylindrical Roller Bearings Was Significantly Improved With The Aid Of New Calculation And Manufacturing Methods. Optimum Contact Conditions Between The Roller And Rib Are Ensured By Means Of A Special Curvature Of The Roller End Faces. As A Result, The Axial Contact Pressures On The Rib Are Significantly Minimised And A Lubricant Film Capable Of Supporting Higher Loads Is Formed. Under Normal Operating Conditions, Wear And Fatigue At The Rib Contact Running And Roller End Faces Is Completely Eliminated. In Addition, Axial Frictional Torque Is Reduced By Up To 50%. The Bearing Temperature During Operation Is Therefore Significantly Lower

Internal Clearance Larger Than Normal
