INA SL185034-A-BR-C3-2S

Specifications

Brand	INA
Item Number	SL185034-A-BR-C3-2S INA
Manufacturer Part Number	0100865790034
EAN	4012802572117
Category	Cylindrical Roller Bearing Double Row

Weight and Dimensions

Inner (d) MM	160
Outer (D) MM	240
Width (B) MM	122
Inner (d) Inch	6.2992
Outer (D) Inch	9.4488
Width (B) Inch	4.8031
Weight (kg)	22.5 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	FC - Full Complement, No Cage
External Modification	No External Modification
Radial Internal Play	C3 Internal Play (Higher than Cn)
Precision	BR + 2S
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

Width (b) mm	122
Basic static load rating, radial (C 0r)	2110000
Limiting speed (n G)	1480
Reference speed (n u03d1r)	900
ECLASS number	23-05-09-01
ECLASS2 number	23-05-09-01

Suffix description

A	The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
BR	Black Finished, Factory-Applied Durotect® B Black-Oxide Coating. Durotect B Improves Run-In Behavior And Energy Efficiency While Reducing Surface-Induced Damage To The Bearing, Burnished Race
C3	Internal Clearance Larger Than Normal
2S	Bearings Matched In Set Of Two For Side-By-Side Mounting
