INA SL185018-A-C3-2S

Specifications

Brand	INA
Item Number	SL185018-A-C3-2S INA
Manufacturer Part Number	0002694500034
EAN	4047643221313
Category	Cylindrical Roller Bearing Multi Row

Weight and Dimensions

Inner (d) MM	90
Outer (D) MM	140
Width (B) MM	134
Inner (d) Inch	3.5433
Outer (D) Inch	5.5118
Width (B) Inch	5.2756
Weight (kg)	7.24 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	FC - Full Complement, No Cage
External Modification	No External Modification
Radial Internal Play	C3 Internal Play (Higher than Cn)
Precision	Set of Two for Side-by-Side
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

Width (b) mm	67
Basic static load rating, radial (C 0r)	550000
Limiting speed (n G)	2850
Reference speed (n u03d1r)	2140
ECLASS number	23-05-09-01
ECLASS2 number	23-05-09-01

Suffix description

A	The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
C3	Internal Clearance Larger Than Normal
2S	Bearings Matched In Set Of Two For Side-By-Side Mounting, Tolerance Is Matched Based On The Inner, Outer And Clearance Of The Bearing
