INA SL185013-A

Price: 190.14 $

Specifications

Brand	INA
Item Number	SL185013-A INA
Manufacturer Part Number	0002686400000
Also known as	NNCF5013CV
EAN	4012802418071
Category	Cylindrical Roller Bearing Double Row

Weight and Dimensions

Inner (d) MM	65
Outer (D) MM	100
Width (B) MM	46
Inner (d) Inch	2.5591
Outer (D) Inch	3.937
Width (B) Inch	1.811
Weight (kg)	1.32 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	FC - Full Complement, No Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

Width (b) mm	46
Radial Static Load Rating C0r (N)	315000
Radial Dynamic Load Rating Cr (N)	197000
Basic static load rating, radial (C 0r)	"315000.0000"
Limiting speed (n G)	4000
Reference speed (n u03d1r)	2500
ECLASS number	23-05-09-01
ECLASS2 number	23-05-09-01
Medias description	Cylindrical roller bearing SL1850..-A, full complement roller set, two-row, semi-locating bearing, 1 rib on outer ring, 3 ribs on inner ring, type SL18

Suffix description

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
