INA SL185005-A-C3

Price: 104.63 $

Specifications

Brand	INA
Item Number	SL185005-A-C3 INA
Manufacturer Part Number	0002667870030
Also known as	NNCF5005V/C3
EAN	4054365598821
Category	Cylindrical Roller Bearing Double Row

Weight and Dimensions

Inner (d) MM	25
Outer (D) MM	47
Width (B) MM	30
Inner (d) Inch	0.9843
Outer (D) Inch	1.8504
Width (B) Inch	1.1811
Weight (kg)	0.23 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	FC - Full Complement, No Cage
External Modification	No External Modification
Radial Internal Play	C3 Internal Play (Higher than Cn)
Precision	Standard Precision
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

Width (b) mm	30
Radial Static Load Rating C0r (N)	64000
Radial Dynamic Load Rating Cr (N)	53000
Basic static load rating, radial (C 0r)	"64000.0000"
Limiting speed (n G)	9500
Reference speed (n u03d1r)	6000
ECLASS number	23-05-09-01
ECLASS2 number	23-05-09-01
Medias description	Cylindrical roller bearing SL1850..-A, full complement roller set, two-row, semi-locating bearing, 1 rib on outer ring, 3 ribs on inner ring, type SL18

Suffix description

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

Internal Clearance Larger Than Normal
