INA SL183076-TB-C3

Price: 0.00 $

Specifications

Brand	INA
Item Number	SL183076-TB-C3 INA
Manufacturer Part Number	0535322360030
EAN	4047643141253
Category	Cylindrical Roller Bearing Single Row

Weight and Dimensions

Inner (d) MM	380
Outer (D) MM	560
Width (B) MM	135
Inner (d) Inch	14.9606
Outer (D) Inch	22.0472
Width (B) Inch	5.315
Weight (kg)	106 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	FC - Full Complement, No Cage
External Modification	No External Modification
Radial Internal Play	C3 Internal Play (Higher than Cn)
Precision	Standard Precision
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

Width (b) mm	135
Basic static load rating, radial (C 0r)	4450000
Limiting speed (n G)	660
Reference speed (n u03d1r)	390
ECLASS number	23-05-09-01
ECLASS2 number	23-05-09-01

Suffix description

In The Case Of Bearings Of TB Design, The Axial Load Carrying Capacity Of Cylindrical Roller Bearings Was Significantly Improved With The Aid Of New Calculation And Manufacturing Methods. Optimum Contact Conditions Between The Roller And Rib Are Ensured By Means Of A Special Curvature Of The Roller End Faces. As A Result, The Axial Contact Pressures On The Rib Are Significantly Minimised And A Lubricant Film Capable Of Supporting Higher Loads Is Formed. Under Normal Operating Conditions, Wear And Fatigue At The Rib Contact Running And Roller End Faces Is Completely Eliminated. In Addition, Axial Frictional Torque Is Reduced By Up To 50%. The Bearing Temperature During Operation Is Therefore Significantly Lower

Internal Clearance Larger Than Normal
