INA SL183040-TB-C3

Price: 1,766.55 $

Specifications

Brand	INA
Item Number	SL183040-TB-C3 INA
Manufacturer Part Number	0535288670030
EAN	4047643202589
Category	Cylindrical Roller Bearing Single Row

Weight and Dimensions

Inner (d) MM	200
Outer (D) MM	310
Width (B) MM	82
Inner (d) Inch	7.874
Outer (D) Inch	12.2047
Width (B) Inch	3.2283
Weight (kg)	21.8 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	FC - Full Complement, No Cage
External Modification	No External Modification
Radial Internal Play	C3 Internal Play (Higher than Cn)
Precision	Standard Precision
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

ECLASS number	23-05-09-01
ECLASS2 number	23-05-09-01

Suffix description

In The Case Of Bearings Of TB Design, The Axial Load Carrying Capacity Of Cylindrical Roller Bearings Was Significantly Improved With The Aid Of New Calculation And Manufacturing Methods. Optimum Contact Conditions Between The Roller And Rib Are Ensured By Means Of A Special Curvature Of The Roller End Faces. As A Result, The Axial Contact Pressures On The Rib Are Significantly Minimised And A Lubricant Film Capable Of Supporting Higher Loads Is Formed. Under Normal Operating Conditions, Wear And Fatigue At The Rib Contact Running And Roller End Faces Is Completely Eliminated. In Addition, Axial Frictional Torque Is Reduced By Up To 50%. The Bearing Temperature During Operation Is Therefore Significantly Lower

Internal Clearance Larger Than Normal
