INA SL1818/630-E-TB
Price: 0.00 $
Specifications
| Brand | INA |
| Item Number | SL1818/630-E-TB INA |
| Manufacturer Part Number | 0572452820000 |
| EAN | 4012802395075 |
| Category | Cylindrical Roller Bearing Single Row |
| Inner (d) MM | 630 |
| Outer (D) MM | 780 |
| Width (B) MM | 69 |
| Inner (d) Inch | 24.8031 |
| Outer (D) Inch | 30.7087 |
| Width (B) Inch | 2.7165 |
| Weight (kg) | 70.51 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | FC - Full Complement, No Cage |
| External Modification | No External Modification |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Width (b) mm | 69 |
| Radial Static Load Rating C0r (N) | 3150000 |
| Radial Dynamic Load Rating Cr (N) | 1410000 |
| Basic static load rating, radial (C 0r) | "3150000.0000" |
| Limiting speed (n G) | 425 |
| Reference speed (n u03d1r) | 260 |
| ECLASS number | 23-05-09-01 |
| ECLASS2 number | 23-05-09-01 |
| Medias description | Cylindrical roller bearing, SL1818..-E-TB full complement roller set, single row, semi-locating bearing, 1 rib on outer ring, 2 ribs on inner ring, type SL18 |
| E | Increased Load Capacity |
| TB | In The Case Of Bearings Of TB Design, The Axial Load Carrying Capacity Of Cylindrical Roller Bearings Was Significantly Improved With The Aid Of New Calculation And Manufacturing Methods. Optimum Contact Conditions Between The Roller And Rib Are Ensured By Means Of A Special Curvature Of The Roller End Faces. As A Result, The Axial Contact Pressures On The Rib Are Significantly Minimised And A Lubricant Film Capable Of Supporting Higher Loads Is Formed. Under Normal Operating Conditions, Wear And Fatigue At The Rib Contact Running And Roller End Faces Is Completely Eliminated. In Addition, Axial Frictional Torque Is Reduced By Up To 50%. The Bearing Temperature During Operation Is Therefore Significantly Lower |
FAG 618/630-MA-C3
73.2 kg
630x780x69 mm
FAG 618/630-MA
73.2 kg
630x780x69 mm
FAG 618/630M
73.2 kg
630x780x69 mm
FAG 618/630-M-C3
73.2 kg
630x780x69 mm
SKF 618/630MA
73.2 kg
630x780x69 mm
SKF 618/630MA/C3
73.2 kg
630x780x69 mm
FAG 618/630-MA-C4
72.2 kg
630x780x69 mm
FAG 618/630-M-C4
73.2 kg
630x780x69 mm
FAG 618/630-M
73.2 kg
630x780x69 mm
FAG 618/630MA
73.2 kg
630x780x69 mm
FAG 618/630MA-C3
73.2 kg
630x780x69 mm
NSK 68/630MC3
73.2 kg
630x780x69 mm
RKB 618/630MB C4
73.2 kg
630x780x69 mm
NSK 68/630M C3
73.2 kg
630x780x69 mm
FAG 618/630-MA-C5
73.2 kg
630x780x69 mm
SKF 618/630MA/C4
72.2 kg
630x780x69 mm
RKB 618/630MBS C3
73.2 kg
630x780x69 mm
RKB 618/630MBS
73.2 kg
630x780x69 mm
Neutral 618/630MA C3
73.2 kg
630x780x69 mm
SKF 718/630AMB
71.7 kg
630x780x69 mm
SKF 718/630
69.7 kg
630x780x69 mm
INA SL1818/630-E-TB-BR
70.51 kg
630x780x69 mm
INA SL1818/630-E-TB-C3
68 kg
630x780x69 mm
NSK NCF18/630VCCG280U-01
70.51 kg
630x780x69 mm
FAG NJ18/630-M1-C3
73.354 kg
630x780x69 mm
INA SL1818/630-E-TB-BR-XL
70.51 kg
630x780x69 mm
INA SL1818/630
70.51 kg
630x780x69 mm
INA SL1818/630-A-C4
70.51 kg
630x780x69 mm
SKF NCF18/630V
70.51 kg
630x780x69 mm
Timken NCF18/630V
70.51 kg
630x780x69 mm
SKF NCF18/630V/C3
70.51 kg
630x780x69 mm
SKF NCF18/630V/C4
70.51 kg
630x780x69 mm
RKB NCF18/630V ZB C4
70.51 kg
630x780x69 mm
RKB NCF18/630V ZB C3
70.51 kg
630x780x69 mm
FAG NCF18/630V-C3
68 kg
630x780x69 mm
