INA SL1818/560-E-TB-N1-BR
Price: 0.00 $
Specifications
| Brand | INA |
| Item Number | SL1818/560-E-TB-N1-BR INA |
| Manufacturer Part Number | 0581553410000 |
| EAN | 4047643064095 |
| Category | Cylindrical Roller Bearing Single Row |
| Inner (d) MM | 560 |
| Outer (D) MM | 680 |
| Width (B) MM | 56 |
| Weight (kg) | 39.9 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | FC - Full Complement, No Cage |
| External Modification | N1 - 1 Locking Groove in Outer Ring |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | BR - Black Finishing |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Width (b) mm | 56 |
| Basic static load rating, radial (C 0r) | 2290000 |
| Limiting speed (n G) | 485 |
| Reference speed (n u03d1r) | 300 |
| ECLASS number | 23-05-09-01 |
| ECLASS2 number | 23-05-09-01 |
| E | Increased Load Capacity |
| TB | In The Case Of Bearings Of TB Design, The Axial Load Carrying Capacity Of Cylindrical Roller Bearings Was Significantly Improved With The Aid Of New Calculation And Manufacturing Methods. Optimum Contact Conditions Between The Roller And Rib Are Ensured By Means Of A Special Curvature Of The Roller End Faces. As A Result, The Axial Contact Pressures On The Rib Are Significantly Minimised And A Lubricant Film Capable Of Supporting Higher Loads Is Formed. Under Normal Operating Conditions, Wear And Fatigue At The Rib Contact Running And Roller End Faces Is Completely Eliminated. In Addition, Axial Frictional Torque Is Reduced By Up To 50%. The Bearing Temperature During Operation Is Therefore Significantly Lower |
| N1 | One Locating Slot (Notch) In One Outer Ring Side Face Or Housing Washer |
| BR | Black Finished, Factory-Applied Durotect® B Black-Oxide Coating. Durotect B Improves Run-In Behavior And Energy Efficiency While Reducing Surface-Induced Damage To The Bearing, Burnished Race |
FAG 618/560-MA
41.5 kg
560x680x56 mm
FAG 618/560-MA-C3
41.5 kg
560x680x56 mm
FAG 618/560-M-C3
35.1 kg
560x680x56 mm
FAG 618/560-M
41.5 kg
560x680x56 mm
FAG 618/560MA
41.5 kg
560x680x56 mm
FAG 618/560-MB
41.5 kg
560x680x56 mm
SKF 618/560MA
41.5 kg
560x680x56 mm
SKF 618/560MA/C3
41.5 kg
560x680x56 mm
RKB 618/560MA
41.5 kg
560x680x56 mm
RKB 618/560MA C3
41.5 kg
560x680x56 mm
FAG 618/560MB
41.5 kg
560x680x56 mm
FAG 618/560-M-C5
41.5 kg
560x680x56 mm
FAG 618/560M
41.5 kg
560x680x56 mm
FAG 618/560M-C3
35.1 kg
560x680x56 mm
Steyr 618/560MB
41.5 kg
560x680x56 mm
NKE 618/560-MA
41.5 kg
560x680x56 mm
Kugel & Rollenlager Werk 618/560MA C3 Kugel & Rollenlager Werk
41.5 kg
560x680x56 mm
Neutral 618/560MA C3
41.5 kg
560x680x56 mm
Neutral 618/560MA
41.5 kg
560x680x56 mm
Deutsche Kugellager Fabrik 618/560MA P4
41.5 kg
560x680x56 mm
FAG 718/560-MP-P5
39.8 kg
560x680x56 mm
FAG 718/560-MP-P5-UA
39.8 kg
560x680x56 mm
SKF 718/560A
41.5 kg
560x680x56 mm
INA SL1818/560-E-TB-BR-XL
40.5 kg
560x680x56 mm
INA SL1818/560E-TB-IR/T-CN/3L
39.9 kg
560x680x56 mm
INA SL1818/560-E-TB
40.5 kg
560x680x56 mm
INA SL1818/560-E-TB-N1-IR/T-CN/3L
39.9 kg
560x680x56 mm
FAG NU18/560-M1-C3
41.7 kg
560x680x56 mm
INA SL1818/560-A
40.5 kg
560x680x56 mm
FAG NCF18/560V
40.5 kg
560x680x56 mm
FAG NU18/560-M1A-C3
41.7 kg
560x680x56 mm
INA SL1818/560-E-TB-BR
40.5 kg
560x680x56 mm
SKF NCF18/560V
40.5 kg
560x680x56 mm
RKB NCF18/560VC NR A ZB
40.5 kg
560x680x56 mm
Neutral MR3350
48.5 kg
560x680x56 mm
FAG NJ18/560-M1A-C5
42 kg
560x680x56 mm
