INA SL024930-A-2S

Price: 739.65 $

Specifications

Brand	INA
Item Number	SL024930-A-2S INA
Manufacturer Part Number	0001237900954
EAN	4054365458866
Category	Cylindrical Roller Bearing Double Row

Weight and Dimensions

Inner (d) MM	150
Outer (D) MM	210
Width (B) MM	60
Inner (d) Inch	5.9055
Outer (D) Inch	8.2677
Width (B) Inch	2.3622
Weight (kg)	6.45 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	FC - Full Complement, No Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Set of Two for Side-by-Side
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

Width (b) mm	60
Basic static load rating, radial (C 0r)	820000
Limiting speed (n G)	1790
Reference speed (n u03d1r)	1200
ECLASS number	23-05-09-01
ECLASS2 number	23-05-09-01

Suffix description

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

Bearings Matched In Set Of Two For Side-By-Side Mounting, Tolerance Is Matched Based On The Inner, Outer And Clearance Of The Bearing
