INA SK102-207-KRR-B-AH10

Specifications

Brand	INA
Item Number	SK102-207-KRR-B-AH10 INA
Manufacturer Part Number	0504200200000
EAN	4054366694775
Category	Bearings for Housings

Weight and Dimensions

Inner (d) MM	28,58
Outer (D) MM	72
Width (B) MM	37,7
Inner (d) Inch	1.125
Outer (D) Inch	2.8346
Width (B) Inch	1.4843
Weight (kg)	0.45 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Outside diameter (D SP) mm	72
Width (b) mm	37,7
Basic static load rating, radial (C 0r)	15300
ECLASS number	23-05-08-01
ECLASS2 number	23-05-08-01

Suffix description

KRR	Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
B	Bearing With Spherical Outer Ring
AH10
