INA RWU25-E-H-V3-G2

INA RWU25-E-H-V3-G2
INA RWU25-E-H-V3-G2 rulman resim 1
INA RWU25-E-H-V3-G2 rulman resim 2
INA RWU25-E-H-V3-G2 rulman resim 3
INA RWU25-E-H-V3-G2 rulman resim 4
INA RWU25-E-H-V3-G2 rulman resim 5
Price: 181.30 $
Specifications
Brand INA
Item Number RWU25-E-H-V3-G2 INA
Manufacturer Part Number 0649925001430
Also known as RWU25-E-H-G2-V3
EAN 4054364489496
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 23
Outer (D) MM 48
Width (B) MM 91
Inner (d) Inch 0.9055
Outer (D) Inch 1.8898
Width (B) Inch 3.5827
Weight (kg) 0.65 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 48
Overall length carriage (L) mm 91
Dynamic load rating (C) 28000
Dynamic load rating (C 0) 65000
Static moment rating about X axis (M 0x) 350
Static moment rating about Y axis (M 0y) 760
Static moment rating about Z axis (M 0z) 680
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description High, narrow carriage with full complement recirculating roller system for linear recirculating roller bearing and guideway assembly, for oil or grease lubrication
Suffix description
E Version
H High Carriage
V3 Preload Class 3
G2 Precision Class 2
