INA RSL185016-A

Price: 242.34 $

Specifications

Brand	INA
Item Number	RSL185016-A INA
Manufacturer Part Number	0011786520000
EAN	4012802426571
Category	Cylindrical Roller Bearing Double Row

Weight and Dimensions

Inner (d) MM	80
Outer (D) MM	125
Width (B) MM	60
Inner (d) Inch	3.1496
Outer (D) Inch	4.9213
Width (B) Inch	2.3622
Weight (kg)	2.59 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	FC - Full Complement, No Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

Rib diameter inner ring (d) mm	80
E w mm	116,99
Width (b) mm	60
Radial Static Load Rating C0r (N)	440000
Radial Dynamic Load Rating Cr (N)	290000
Basic static load rating, radial (C 0r)	"440000.0000"
Limiting speed (n G)	3200
Reference speed (n u03d1r)	2330
ECLASS number	23-05-09-01
ECLASS2 number	23-05-09-01
Medias description	Cylindrical roller bearing RSL18, full complement roller set, two-row, semi-locating bearing, no outer ring, 3 ribs on inner ring, type RSL18

Suffix description

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
