INA RSL185009-A

Specifications

Brand	INA
Item Number	RSL185009-A INA
Manufacturer Part Number	0003832520000
EAN	4012802606515
Category	Cylindrical Roller Bearing Single Row

Weight and Dimensions

Inner (d) MM	45
Outer (D) MM	66,8528
Width (B) MM	40
Inner (d) Inch	1.7717
Outer (D) Inch	2.632
Width (B) Inch	1.5748
Weight (kg)	0.4 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	FC - Full Complement, No Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

Rib diameter inner ring (d) mm	45
E w mm	66,85
Width (b) mm	40
Radial Static Load Rating C0r (N)	148000
Radial Dynamic Load Rating Cr (N)	106000
Basic static load rating, radial (C 0r)	"148000.0000"
Limiting speed (n G)	5800
Reference speed (n u03d1r)	3800
ECLASS number	23-05-09-01
ECLASS2 number	23-05-09-01
Medias description	Cylindrical roller bearing RSL18, full complement roller set, two-row, semi-locating bearing, no outer ring, 3 ribs on inner ring, type RSL18

Suffix description

A

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
