INA RSL185008-A

Price: 77.42 $

Specifications

Brand	INA
Item Number	RSL185008-A INA
Manufacturer Part Number	0014424900000
EAN	4012802706956
Category	Cylindrical Roller Bearing Single Row

Weight and Dimensions

Inner (d) MM	40
Inner (d) Inch	1.5748
Weight (kg)	0.349 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	FC - Full Complement, No Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

Rib diameter inner ring (d) mm	40
E w mm	61,74
Width (b) mm	38
Radial Static Load Rating C0r (N)	133000
Radial Dynamic Load Rating Cr (N)	100000
Basic static load rating, radial (C 0r)	"133000.0000"
Limiting speed (n G)	6300
Reference speed (n u03d1r)	4150
ECLASS number	23-05-09-01
ECLASS2 number	23-05-09-01
Medias description	Cylindrical roller bearing RSL18, full complement roller set, two-row, semi-locating bearing, no outer ring, 3 ribs on inner ring, type RSL18

Suffix description

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
