INA RSL182220-A

Specifications

Brand	INA
Item Number	RSL182220-A INA
Manufacturer Part Number	0000588660000
EAN	4012802068429
Category	Cylindrical Roller Bearing Single Row

Weight and Dimensions

Inner (d) MM	100
Outer (D) MM	162,81
Width (B) MM	46
Inner (d) Inch	3.937
Outer (D) Inch	6.4098
Width (B) Inch	1.811
Weight (kg)	3.35 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	FC - Full Complement, No Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

E w mm	162,81
Width (b) mm	46
Radial Static Load Rating C0r (N)	510000
Radial Dynamic Load Rating Cr (N)	390000
Limiting speed (n G)	2300
ECLASS number	23-05-09-01
ECLASS2 number	23-05-09-01
Medias description	Cylindrical roller bearing RSL18, full complement roller set, single row, non-locating bearing, no outer ring, 2 ribs on inner ring, type RSL18

Suffix description

A

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
