INA RSL182209-A-XL-2S

Specifications

Brand	INA
Item Number	RSL182209-A-XL-2S INA
Manufacturer Part Number	0501953520954
Also known as	RSL182209-A-2S
EAN	4012802731248
Category	Cylindrical Roller Bearing Single Row

Weight and Dimensions

Inner (d) MM	45
Outer (D) MM	74,43
Width (B) MM	23
Weight (kg)	0.33 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	No Seal
Cage Type	FC - Full Complement, No Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Set of Two for Side-by-Side
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

E w mm	74,43
Width (b) mm	23
Basic static load rating, radial (C 0r)	98000
Limiting speed (n G)	5300
ECLASS number	23-05-09-01
ECLASS2 number	23-05-09-01

Suffix description

A	The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
XL	X-Life
2S	Bearings Matched In Set Of Two For Side-By-Side Mounting, Tolerance Is Matched Based On The Inner, Outer And Clearance Of The Bearing
