INA RME40-XL-N

Specifications

Brand	INA
Item Number	RME40-XL-N INA
Manufacturer Part Number	0096431410000
Also known as	RME40-N
EAN	4012802837773
Category	Housing and Bearing (assembly)

Weight and Dimensions

Inner (d) MM	40
Outer (D) MM	145
Width (B) MM	46,4
Inner (d) Inch	1.5748
Outer (D) Inch	5.7087
Width (B) Inch	1.8268
Weight (kg)	2.15 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Height flange (H) mm	145
Locking collar total width (B 1) mm	56,5
Total height unit (U) mm	33,9
Radial Static Load Rating C0r (N)	19800
Radial Dynamic Load Rating Cr (N)	34500
Basic static load rating, radial (C 0r)	"19800.0000"
ECLASS number	23-05-16-02
ECLASS2 number	23-05-16-02
Medias description	Housing units RME, four-bolt flanged housing units, cast iron, centring spigot, eccentric locking collar, R seals

Suffix description

XL	X-Life
N	Cast Iron Housing With Undercut Slot For End Caps
