INA RCJY40-XL-N
Price: 46.05 $
Specifications
| Brand | INA |
| Item Number | RCJY40-XL-N INA |
| Manufacturer Part Number | 0008584200000 |
| Also known as |
RCJY40-N |
| EAN | 4012802797879 |
| Category | Housing and Bearing (assembly) |
| Inner (d) MM | 40 |
| Outer (D) MM | 130 |
| Width (B) MM | 54,2 |
| Inner (d) Inch | 1.5748 |
| Outer (D) Inch | 5.1181 |
| Width (B) Inch | 2.1339 |
| Weight (kg) | 1.82 kg |
| Seal | 2F - Standard Seal for Y-bearings |
| Lubrication | Standard Lubrication |
| Special Treatment | No Special Treatment |
| Flange width (L) mm | 130 |
| Total height unit (U) mm | 54,2 |
| Radial Static Load Rating C0r (N) | 19800 |
| Radial Dynamic Load Rating Cr (N) | 34500 |
| Basic static load rating, radial (C 0r) | "19800.0000" |
| ECLASS number | 23-05-16-02 |
| ECLASS2 number | 23-05-16-02 |
| Medias description | Housing units RCJY, four-bolt flanged housing units, cast iron, grub screws in inner ring, R seals |
| XL | X-Life |
| N | Cast Iron Housing With Undercut Slot For End Caps |
