INA RCJY35-XL-N

INA RCJY35-XL-N
INA RCJY35-XL-N rulman resim 1
INA RCJY35-XL-N rulman resim 2
INA RCJY35-XL-N rulman resim 3
INA RCJY35-XL-N rulman resim 4
Price: 36.16 $
Specifications
Brand INA
Item Number RCJY35-XL-N INA
Manufacturer Part Number 0008584120000
Also known as RCJY35-N
EAN 4012802797893
Category Housing and Bearing (assembly)
Weight and Dimensions
Inner (d) MM 35
Outer (D) MM 118
Width (B) MM 46,4
Inner (d) Inch 1.378
Outer (D) Inch 4.6457
Width (B) Inch 1.8268
Weight (kg) 1.355 kg
Product Properties
Seal 2F - Standard Seal for Y-bearings
Lubrication Standard Lubrication
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Flange width (L) mm 118
Total height unit (U) mm 46,4
Radial Static Load Rating C0r (N) 15300
Radial Dynamic Load Rating Cr (N) 27500
Basic static load rating, radial (C 0r) "15300.0000"
ECLASS number 23-05-16-02
ECLASS2 number 23-05-16-02
Medias description Housing units RCJY, four-bolt flanged housing units, cast iron, grub screws in inner ring, R seals
Suffix description
XL X-Life
N Cast Iron Housing With Undercut Slot For End Caps
