INA RCJY25-XL-N

INA RCJY25-XL-N
INA RCJY25-XL-N rulman resim 1
INA RCJY25-XL-N rulman resim 2
INA RCJY25-XL-N rulman resim 3
INA RCJY25-XL-N rulman resim 4
Price: 24.36 $
Specifications
Brand INA
Item Number RCJY25-XL-N INA
Manufacturer Part Number 0008674460000
Also known as RCJY25-N
EAN 4012802796414
Category Housing and Bearing (assembly)
Weight and Dimensions
Inner (d) MM 25
Outer (D) MM 95
Width (B) MM 38,8
Inner (d) Inch 0.9843
Outer (D) Inch 3.7402
Width (B) Inch 1.5276
Weight (kg) 0.83 kg
Product Properties
Seal 2F - Standard Seal for Y-bearings
Lubrication Standard Lubrication
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Flange width (L) mm 95
Total height unit (U) mm 38,8
Radial Static Load Rating C0r (N) 7800
Radial Dynamic Load Rating Cr (N) 14900
Basic static load rating, radial (C 0r) "7800.0000"
ECLASS number 23-05-16-02
ECLASS2 number 23-05-16-02
Medias description Housing units RCJY, four-bolt flanged housing units, cast iron, grub screws in inner ring, R seals
Suffix description
XL X-Life
N Cast Iron Housing With Undercut Slot For End Caps
INA RCJY25
INA RCJY25
0.83 kg
25x95x38,8 mm
24 ₺
SKF FYKC25NTH
SKF FYKC25NTH
0.333 kg
25x95x38,8 mm
96 ₺
SKF FY25TR
SKF FY25TR
0.729 kg
25x95x38,8 mm
36 ₺
RHP TSF25
RHP TSF25
0.83 kg
25x95x38,8 mm
48 ₺
SKF UCF205/H
SKF UCF205/H
0.8 kg
25x95x38,8 mm
17 ₺
SKF FYK25TR
SKF FYK25TR
0.33 kg
25x95x38,8 mm
27 ₺
SKF FYKC25NTR/VE495
SKF FYKC25NTR/VE495
0.333 kg
25x95x38,8 mm
115 ₺
SKF FY25TF
SKF FY25TF
0.83 kg
25x95x38,8 mm
20 ₺
RHP SF25
RHP SF25
0.83 kg
25x95x38,8 mm
29 ₺
Dodge 125887
Dodge 125887
0.83 kg
25x95x38,8 mm
27 ₺
Koyo (JTEKT) UCF205J T2
Koyo (JTEKT) UCF205J T2
0.83 kg
25x95x38,8 mm
25 ₺
SNR UCFE205
SNR UCFE205
0.83 kg
25x95x38,8 mm
27 ₺
Dodge F4B-SC-25M
Dodge F4B-SC-25M
0.83 kg
25x95x38,8 mm
27 ₺
Koyo (JTEKT) UCF205J P2
Koyo (JTEKT) UCF205J P2
0.83 kg
25x95x38,8 mm
15 ₺
SNR UCFE-205
SNR UCFE-205
0.83 kg
25x95x38,8 mm
27 ₺
FAG FG56205
FAG FG56205
0.83 kg
25x95x38,8 mm
21 ₺
FAG F56205
FAG F56205
0.83 kg
25x95x38,8 mm
27 ₺
INA RCJY25-N
INA RCJY25-N
0.83 kg
25x95x38,8 mm
24 ₺
SKF FY25TF/VA201
SKF FY25TF/VA201
0.83 kg
25x95x38,8 mm
124 ₺
SKF FY25TM
SKF FY25TM
0.83 kg
25x95x38,8 mm
--
SKF FYK25TF
SKF FYK25TF
0.332 kg
25x95x38,8 mm
24 ₺
SKF FY25SD
SKF FY25SD
0.83 kg
25x95x38,8 mm
20 ₺
RHP SF25FS
RHP SF25FS
0.729 kg
25x95x38,8 mm
31 ₺
SKF FY25TF/VA228
SKF FY25TF/VA228
0.83 kg
25x95x38,8 mm
121 ₺
NSK SF25
NSK SF25
0.83 kg
25x95x38,8 mm
25 ₺
Sealmaster SF25
Sealmaster SF25
0.83 kg
25x95x38,8 mm
27 ₺
Fafnir YCJ25
Fafnir YCJ25
0.83 kg
25x95x38,8 mm
27 ₺
NTN M-SM-UCF205D1
NTN M-SM-UCF205D1
0.83 kg
25x95x38,8 mm
27 ₺
SNR SF25
SNR SF25
0.83 kg
25x95x38,8 mm
27 ₺
TR FY25TF
TR FY25TF
0.83 kg
25x95x38,8 mm
14 ₺
Neutral NUCF205
Neutral NUCF205
0.83 kg
25x95x38,8 mm
4 ₺
Neutral TP-SUCF205BLACK
Neutral TP-SUCF205BLACK
0.332 kg
25x95x38,8 mm
--
INA RCJY25N
INA RCJY25N
0.83 kg
25x95x38,8 mm
27 ₺
INA RCJY25-TV-VA-FD
INA RCJY25-TV-VA-FD
0.83 kg
25x95x38,8 mm
--
SKF Y/UCF205/H
SKF Y/UCF205/H
0.8 kg
25x95x38,8 mm
17 ₺
