INA RCJTZ35-XL
Price: 57.73 $
Specifications
| Brand | INA |
| Item Number | RCJTZ35-XL INA |
| Manufacturer Part Number | 0008316970000 |
| Also known as |
RCJTZ35 |
| EAN | 4012802791167 |
| Category | Housing and Bearing (assembly) |
| Inner (d) MM | 35 |
| Outer (D) MM | 155 |
| Width (B) MM | 49,3 |
| Inner (d) Inch | 1.378 |
| Outer (D) Inch | 6.1024 |
| Width (B) Inch | 1.9409 |
| Weight (kg) | 1.22 kg |
| Seal | 2F - Standard Seal for Y-bearings |
| Lubrication | Standard Lubrication |
| Special Treatment | No Special Treatment |
| Flange width (L) mm | 94 |
| Height flange (H) mm | 155 |
| Total height unit (U) mm | 49,5 |
| Radial Static Load Rating C0r (N) | 15300 |
| Radial Dynamic Load Rating Cr (N) | 27500 |
| Basic static load rating, radial (C 0r) | "15300.0000" |
| ECLASS number | 23-05-16-02 |
| ECLASS2 number | 23-05-16-02 |
| Medias description | Housing units RCJTZ, two-bolt flanged housing units, cast iron, centring spigot, eccentric locking collar, R seals |
| XL | X-Life |
