INA RCJTA35-XL-N
Price: 68.64 $
Specifications
| Brand | INA |
| Item Number | RCJTA35-XL-N INA |
| Manufacturer Part Number | 0009737930000 |
| Also known as |
GSH35-2RSRB+CJT07N+KASK07 |
| EAN | 4012802820447 |
| Category | Housing and Bearing (assembly) |
| Inner (d) MM | 35 |
| Outer (D) MM | 155 |
| Width (B) MM | 46 |
| Inner (d) Inch | 1.378 |
| Outer (D) Inch | 6.1024 |
| Width (B) Inch | 1.811 |
| Weight (kg) | 1.06 kg |
| Seal | 2F - Standard Seal for Y-bearings |
| Lubrication | Standard Lubrication |
| Special Treatment | No Special Treatment |
| Flange width (L) mm | 92 |
| Height flange (H) mm | 155 |
| Total height unit (U) mm | 46 |
| Radial Static Load Rating C0r (N) | 15700 |
| Radial Dynamic Load Rating Cr (N) | 26500 |
| Basic static load rating, radial (C 0r) | "15300.0000" |
| ECLASS number | 23-05-16-02 |
| ECLASS2 number | 23-05-16-02 |
| Medias description | Housing units RCJTA, two-bolt flanged housing units, cast iron, adapter sleeve, R seals |
| XL | X-Life |
| N | Cast Iron Housing With Undercut Slot For End Caps |
INA RCJTA35-N
1.06 kg
35x155x46 mm
Neutral RCJTA35-N
1.06 kg
35x155x46 mm
