INA RCJL50-XL-N
Price: 85.32 $
Specifications
| Brand | INA |
| Item Number | RCJL50-XL-N INA |
| Manufacturer Part Number | 0009710810000 |
| Also known as |
RCJL50-N |
| EAN | 4012802821116 |
| Category | Housing and Bearing (assembly) |
| Inner (d) MM | 50 |
| Outer (D) MM | 143 |
| Width (B) MM | 58,2 |
| Inner (d) Inch | 1.9685 |
| Outer (D) Inch | 5.6299 |
| Width (B) Inch | 2.2913 |
| Weight (kg) | 2.29 kg |
| Seal | 2F - Standard Seal for Y-bearings |
| Lubrication | Standard Lubrication |
| Special Treatment | No Special Treatment |
| Flange width (L) mm | 143 |
| Total height unit (U) mm | 58,2 |
| Radial Static Load Rating C0r (N) | 23200 |
| Radial Dynamic Load Rating Cr (N) | 37500 |
| Basic static load rating, radial (C 0r) | "23200.0000" |
| ECLASS number | 23-05-16-02 |
| ECLASS2 number | 23-05-16-02 |
| Medias description | Housing units RCJL, four-bolt flanged housing units, cast iron, non-locating bearing, drive slot on inner ring, R seals |
| XL | X-Life |
| N | Cast Iron Housing With Undercut Slot For End Caps |
INA RCJL50-N
2.29 kg
50x143x58,2 mm
