INA RATR35-XL

Specifications

Brand	INA
Item Number	RATR35-XL INA
Manufacturer Part Number	0009532450000
Also known as	RATR35
EAN	4012802823561
Category	Housing and Bearing (assembly)

Weight and Dimensions

Inner (d) MM	35
Outer (D) MM	122
Width (B) MM	38,9
Inner (d) Inch	1.378
Outer (D) Inch	4.8031
Width (B) Inch	1.5315
Weight (kg)	0.66 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Height flange (H) mm	122
Total height unit (U) mm	31,9
Radial Static Load Rating C0r (N)	15300
Radial Dynamic Load Rating Cr (N)	27500
Basic static load rating, radial (C 0r)	"15300.0000"
Load carrying capacity (housing) (C 0r G)	6400
Load carrying capacity (housing) (C g)	6400
ECLASS number	23-05-16-02
ECLASS2 number	23-05-16-02
Medias description	Housing units RATR, three-bolt flanged housing units, sheet steel, eccentric locking collar, P seals

Suffix description

XL

X-Life
