INA RAT17-XL
Price: 21.39 $
Specifications
| Brand | INA |
| Item Number | RAT17-XL INA |
| Manufacturer Part Number | 0008280410000 |
| Also known as |
RAT17 |
| EAN | 4012802793383 |
| Category | Housing and Bearing (assembly) |
| Inner (d) MM | 17 |
| Outer (D) MM | 81 |
| Width (B) MM | 24,1 |
| Inner (d) Inch | 0.6693 |
| Outer (D) Inch | 3.189 |
| Width (B) Inch | 0.9488 |
| Weight (kg) | 0.19 kg |
| Seal | 2F - Standard Seal for Y-bearings |
| Lubrication | Standard Lubrication |
| Special Treatment | No Special Treatment |
| Flange width (L) mm | 58,7 |
| Height flange (H) mm | 81 |
| Total height unit (U) mm | 24 |
| Radial Static Load Rating C0r (N) | 4750 |
| Radial Dynamic Load Rating Cr (N) | 10100 |
| Basic static load rating, radial (C 0r) | "4750.0000" |
| Load carrying capacity (housing) (C 0r G) | 2700 |
| Load carrying capacity (housing) (C g) | 2700 |
| ECLASS number | 23-05-16-02 |
| ECLASS2 number | 23-05-16-02 |
| Medias description | Housing units RAT, two-bolt flanged housing units, sheet steel, eccentric locking collar, P seals |
| XL | X-Life |
