INA RAT12-XL

Specifications

Brand	INA
Item Number	RAT12-XL INA
Manufacturer Part Number	0008280250000
Also known as	RAT12
EAN	4012802793420
Category	Housing and Bearing (assembly)

Weight and Dimensions

Inner (d) MM	12
Outer (D) MM	81
Width (B) MM	24,1
Inner (d) Inch	0.4724
Outer (D) Inch	3.189
Width (B) Inch	0.9488
Weight (kg)	0.21 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Flange width (L) mm	58,7
Height flange (H) mm	81
Total height unit (U) mm	24
Radial Static Load Rating C0r (N)	4750
Radial Dynamic Load Rating Cr (N)	10100
Basic static load rating, radial (C 0r)	"4750.0000"
Load carrying capacity (housing) (C 0r G)	2700
Load carrying capacity (housing) (C g)	2700
ECLASS number	23-05-16-02
ECLASS2 number	23-05-16-02
Medias description	Housing units RAT, two-bolt flanged housing units, sheet steel, eccentric locking collar, P seals

Suffix description

XL

X-Life
