INA RA15-XL
Price: 18.37 $
Specifications
| Brand | INA |
| Item Number | RA15-XL INA |
| Manufacturer Part Number | 0008292500000 |
| Also known as |
RA15 |
| EAN | 4012802792805 |
| Category | Housing and Bearing (assembly) |
| Inner (d) MM | 15 |
| Outer (D) MM | 81 |
| Width (B) MM | 24,1 |
| Inner (d) Inch | 0.5906 |
| Outer (D) Inch | 3.189 |
| Width (B) Inch | 0.9488 |
| Weight (kg) | 0.25 kg |
| Seal | 2F - Standard Seal for Y-bearings |
| Lubrication | Standard Lubrication |
| Special Treatment | No Special Treatment |
| Height flange (H) mm | 81 |
| Locking collar total width (B 1) mm | 28,6 |
| Total height unit (U) mm | 24 |
| Radial Static Load Rating C0r (N) | 4750 |
| Radial Dynamic Load Rating Cr (N) | 10100 |
| Basic static load rating, radial (C 0r) | "4750.0000" |
| Load carrying capacity (housing) (C 0r G) | 2700 |
| ECLASS number | 23-05-16-02 |
| ECLASS2 number | 23-05-16-02 |
| Medias description | Flanged housing unit RA..-XL |
| XL | X-Life |
INA RAT15-XL
0.2 kg
15x81x24,1 mm
RHP SLFL15EC
0.2 kg
15x81x24,1 mm
TR SAPF202
0.25 kg
15x81x24,1 mm
INA RAT15 F-1588
0.2 kg
15x81x24,1 mm
RHP SLFE15EC
0.25 kg
15x81x24,1 mm
SKF PFT15FM
0.2 kg
15x81x24,1 mm
KDF BPFL202SA
0.2 kg
15x81x24,1 mm
MSB SAPF202
0.25 kg
15x81x24,1 mm
FYH SAPFL202
0.2 kg
15x81x24,1 mm
NBR SAPFL202
0.2 kg
15x81x24,1 mm
