INA PWKRE72-2RS-XL

Specifications

Brand	INA
Item Number	PWKRE72-2RS-XL INA
Manufacturer Part Number	0645547160000
Also known as	PWKRE72-2RS
EAN	4047643212045
Category	Cam Follower

Weight and Dimensions

Inner (d) MM	28
Outer (D) MM	72
Width (B) MM	28
Inner (d) Inch	1.1024
Outer (D) Inch	2.8346
Width (B) Inch	1.1024
Weight (kg)	1.05 kg

Product Properties

Seal	2RS - Rubber Seal on Two Sides
Excenterring	E - Excenterring with Inbus Mount
Running Surface	Standard

Data from Schaeffler (medias)

Fit diameter of roller stud / stud (d 1) mm	24
Width (b) mm	80
Basic dynamic load rating, radial (C r w)	39000
Basic static load rating, radial (C 0r)	53000
Speed on permanent grease lubrication (n D G)	2200
ECLASS number	23-05-15-02
ECLASS2 number	23-05-15-02
Medias description	Stud type track rollers PWKRE..-2RS, with axial guidance, full complement cylindrical roller set, with eccentric collar, lip seals on both sides

Suffix description

2RS	Rubber Seals At Each Side Of The Bearing, Temperature Range -30u2103/+120u2103
XL	X-Life
