INA PME30-XL-N

Specifications

Brand	INA
Item Number	PME30-XL-N INA
Manufacturer Part Number	0074430990000
Also known as	PME30-N
EAN	4012802812688
Category	Housing and Bearing (assembly)

Weight and Dimensions

Inner (d) MM	30
Outer (D) MM	125
Width (B) MM	35,8
Inner (d) Inch	1.1811
Outer (D) Inch	4.9213
Width (B) Inch	1.4094
Weight (kg)	0.97 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Height flange (H) mm	125
Locking collar total width (B 1) mm	35,8
Total height unit (U) mm	24,7
Radial Static Load Rating C0r (N)	11300
Radial Dynamic Load Rating Cr (N)	20700
Basic static load rating, radial (C 0r)	"11300.0000"
ECLASS number	23-05-16-02
ECLASS2 number	23-05-16-02
Medias description	Housing units PME, four-bolt flanged housing units, cast iron, centring spigot, eccentric locking collar, P seals

Suffix description

XL	X-Life
N	Cast Iron Housing With Undercut Slot For End Caps
