INA PME25-XL-N

Specifications

Brand	INA
Item Number	PME25-XL-N INA
Manufacturer Part Number	0096434600000
Also known as	PME25-N
EAN	4012802837629
Category	Housing and Bearing (assembly)

Weight and Dimensions

Inner (d) MM	25
Outer (D) MM	115
Width (B) MM	31
Inner (d) Inch	0.9843
Outer (D) Inch	4.5276
Width (B) Inch	1.2205
Weight (kg)	0.74 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Height flange (H) mm	115
Locking collar total width (B 1) mm	31
Total height unit (U) mm	21
Radial Static Load Rating C0r (N)	7800
Radial Dynamic Load Rating Cr (N)	14900
Basic static load rating, radial (C 0r)	"7800.0000"
ECLASS number	23-05-16-02
ECLASS2 number	23-05-16-02
Medias description	Housing units PME, four-bolt flanged housing units, cast iron, centring spigot, eccentric locking collar, P seals

Suffix description

XL	X-Life
N	Cast Iron Housing With Undercut Slot For End Caps
